What Fluid is Used in Liquid Cold Plates? Water vs. Glycol vs. Dielectric Fluids
Executive Summary:
While there are many options, the most common coolant for Liquid Cold Plates is a mixture of Water and Ethylene Glycol (WEG) or Propylene Glycol (WPG).
Water: Offers the best heat transfer but carries corrosion and freezing risks.
Glycol: Added to prevent freezing and inhibit bacterial growth.
Dielectric Fluids (Fluorinated): Used primarily for direct immersion cooling or specific high-voltage applications, but are significantly more expensive.
The ideal choice depends on your operating temperature, material compatibility (Copper vs. Aluminum), and budget.
The 3 Main Types of Coolants for Thermal Management
To maximize the efficiency of your liquid cooling loop, thermal engineers must match the coolant’s specific heat capacity and viscosity to the cold plate’s internal geometry.
1. Water & Glycol Mixtures (The Industry Standard)
Pure water has the highest specific heat capacity of any common fluid, making it the absolute best medium for absorbing heat.
The Engineering Reality: We rarely use 100% pure water in industrial loops because it freezes at 0°C and fosters biological growth. Instead, engineers use a mixture of water and Propylene Glycol (PG) or Ethylene Glycol (EG), fortified with corrosion inhibitors. This prevents the coolant from freezing, prevents algae growth, and protects the internal channels of aluminum cold plates from corrosion.
- Pros: Adding Glycol (Antifreeze) to water prevents the system from freezing in low temperatures and includes additives to prevent galvanic corrosion between dissimilar metals (e.g., Copper tubing in an Aluminum plate).
Cons: Slightly lower thermal performance than pure water; viscosity increases at low temperatures.
Best For: Industrial automation, EV battery cooling, and outdoor telecom equipment.
👉 [View our Tube Embedded Cold Plates]
2.Deionized (DI) / Ultra-Pure Water – The Performance King
Pure water has the absolute highest specific heat capacity of any common fluid, making it the most efficient medium for absorbing heat. It is also low-cost and environmentally friendly.
The Engineering Reality: While DI water is initially non-conductive, it is a highly aggressive solvent. It actively strips ions from metals to re-mineralize itself. If used in a standard aluminum cold plate, it will rapidly cause severe internal corrosion. Furthermore, once contaminated by metal ions, it instantly loses its insulating properties. If you spec DI water, your cold plate must use stainless steel, copper, or nickel-plated internal channels.
- Pros: Water has excellent thermal conductivity and low viscosity, making it the most efficient heat transfer medium.
Cons: Pure water is corrosive to metals (especially Aluminum) and conducts electricity if ions re-enter the solution over time.
Best For: Laboratory equipment or systems with strict corrosion inhibitors and non-conductive requirements.
3.Dielectric Fluids (Fluorinated / Mineral Oil) – The Safety Specialist
Fluorinated fluids (such as 3M™ Novec™) are engineered, non-conductive liquids. If a leak occurs, they will not short-circuit your electronics.
The Engineering Reality: Their thermal capacity is less than half that of water. To achieve the same cooling performance, your pump must work significantly harder to increase the flow rate. They are also exceedingly expensive, making them better suited for direct immersion cooling rather than flowing through closed-loop cold plates.
- Pros: These are non-conductive (insulators). Even if a leak occurs, it will not short-circuit the electronics. Fluorinated fluids (like 3M Novec) have low viscosity and are non-flammable.
Cons: Extremely high cost (often 10x-50x of water). Mineral oil is messy and hard to clean.
Best For: Direct-to-Chip cooling in supercomputers or Immersion Cooling tanks where the hardware is submerged.
Comparison Matrix: Selecting the Right Fluid
| Feature | Deionized Water | Water-Glycol (WEG/WPG) | Fluorinated Fluid (Dielectric) |
| Thermal Conductivity | ⭐⭐⭐⭐⭐ (Best) | ⭐⭐⭐⭐ (Good) | ⭐⭐⭐ (Moderate) |
| Electrical Insulation | Low (Risk of conductivity) | Low | High (Safe for leaks) |
| Corrosion Risk | High (Requires inhibitors) | Low (With additives) | None (Inert) |
| Cost | (Low) | (Medium) | (Very High) |
| Typical Application | Lab, Medical Lasers | General Industry, EV, Power | HPC, Data Center Immersion |
Critical Engineering Tip: Material Compatibility
Don’t Forget Galvanic Corrosion!
When selecting a fluid, you must consider the material of your Liquid Cold Plate.
If you use an Aluminum Cold Plate, avoid using plain water with Copper fittings in the same loop, as this creates a battery effect (Galvanic Corrosion), eating away the aluminum.
Solution: Use a glycol mixture with appropriate corrosion inhibitors, or choose our Vacuum Brazed Cold Plates which can be treated with nickel plating for protection.
